BETTER offers a completeline of centrifugal sand pumps, sizes range from 3x2 to 10x8;

Bare pumps, horizontalpackages, vertical packages, overhead belt driven configurations are available,starters are optional;

Explosion-proof electricmotors are available up to 200HP in 1200, 1500, 1800, 2400, 3600 RPM;

To transfer the drillingfluid in the solid control system, feeding desander, desilter, shale shaker andcentrifuge, or to match with mud hopper for mud mixer, or as charging pump ofmud pump, playing an important role;

Completely identical sizewith those brand pumps in the markets; 100% interchangeable spare parts;

Mechanical seal andpacking seals are both available.

BETTERMission Magnum style Centrifugal Pump-Open Impeller

It has an open impellerdesign that contains wide-tipped vanes and a more tangential circumference ofthe suction allowing the pump to create a smoother flow pattern when handlingabrasive fluids. It is available in hard ductile iron, high chrome alloy fluidends. The pumps can be unitized with electric motors, diesel engines, andhydraulic motors (horizontal, vertical, or close-coupled configuration). Sizesfrom 3x2x13 to 10x8x14.

BETTERMCM 250 style Centrifugal Pump-Semi Open Impeller

It has a semi-openimpeller design that contains wide-tipped vanes and a more tangentialcircumference of the suction allowing the pump to create a smoother flowpattern when handling abrasive fluids.Sizes from 3x2x13 to 10x8x14.

BETTERMission Sandmaster style Centrifugal Pump-Short frame

It has more compact designand can be adapted for hydraulic motor drive. These features make it ideal foruse in application such as oilfield frac truck, cementing, charge pump forwater well drilling. The frame and shaft has been shorten 4” to compare withthe general series. It is a choice when space is a premium and prime moveroptions and limited. Sizes from 3x2x13 to 10x8x14.

BETTERMission Spacesaver style Centrifugal Pump – Close Coupled

It has a very small footprint for applications where space is a premium. These heavy duty pumps requireminimum mounting space and are close-coupled, eliminating couplings and couplingalignment considerations. Sizes from 1x1? to 3x4.

BETTERMission XP style Centrifugal Pump - Large Volume

It is ideally suited forpumping high volumes of heavy slurries that are abrasive, corrosive. Anexcellent choice for high volume mobile and stationary applications where asmall footprint is critical. Sizes 8X6X18, 12x10x23

BETTERMission Magnum Vertical style Centrifugal Pump

The Vertical centrifugalpump provides the good solution for those small space on the floor. Commonapplications include Mud Pumping-offshore/onshore, Solids Control, andDredging.

BETTER High EfficiencyMission Style Shear Pump

Horizontal centrifugalpump structure, belt driven for high speed work; Stainless steel turbine andshear plate to ensure the continuous shear force;To improve bentonite particleshydration degree, reduces the bentonite clay need by 30%.

Pump Spare Parts

All BETTER pumps are builtusing the excellent quality components, and its parts are 100% identical in alldimensions to Mission, Halco, SPD Baker Mud Hog, MCM 250 series, Mattco,Harrisburg, and etc. Including casing assy., impeller(open & semi-open),stuffing box, wear pad, mechanical seal, shaft, shaft sleeve, shaft packing,power end gaskets, fluid end gaskets, oil seal kits, inboard bearing, outboardbearing, bearing covers, housing, etc.
