Height:From 20 m to 50 m

Thickness:1 mm to 30 mm

Suit for:Airport ,seaport , plaza, stadium , square ,highway, street wayetc

Shape:Conoid ,Multi-pyramidal , Columniform,polygonal or conical

Material:Usually   Q345B/A572,minimum yieldstrength>=345n/mm2

As well as Hot rolled coilfrom Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52-

Tolerance of dimension:+- 2%

Power:400W- 5000 W

Light panel:Various figure of selection ,material with hot dipgalvanization steel frame ,stainless steel ,special aluminum plate

Light Extension:Up to 30 000m2

Lamp &Luminaire:Projector generally to be applied with safety gradeIP65

Luminaire with high pressure sodium lamp of long lift and high lightingefficiency ,or metal halide lamp with high CRI

Lifting system:Lifter fixed in the inner of the pole with lifting speedof 3~5 meter per minute

Equipped electromagnetism brake and break proof device, manual operationapplied under power cut

Electric appliance control device

Electric appliance box to bethe holder of the pole ,lifting operation could be 5 meter away from the polethrough wire

Time control and lightcontrol could be equipped to realize full-load lighting mode and part lightingmode
