Layout of metal Sheet Embossing Machine Line: Uncoiling-Feeding Guide-Embossing-Levelling-Recoiling
Technical Parameters of the metal Sheet Embossing Machine Line, aluminum or stainless steel:
5T Hydraulic Decoiler With Coil Car.
Motor power of uncoil: 3.5 KW
Power of hydraulic expansion: 2.2KW
Raw material: Q195/Q235 Prepainted Steel Coil.
Inner diameter of coil: 508mm_610mm.
Outer diameter of coil: φ 1200mm.
Weight of Coil: 5T;
Thickness of sheet: 0.4mm;
Width of sheet: 850mm;
Speed of uncoil: 8-15m/min.

metal Sheet Embossing Machine Line:
Coil Width of the Embosser: 850mm.
Coil Thickness: 0.4mm.
Working Speed: 15m/min.
Material of Rollers: CR12MOV forged steel.
Hardness of Roller: HRC55-58.
Roller Size: 280mmx1000mm
Main Power: 11KW
Depth of Patterns on the steel sheets or aluminum sheets during embossing: Adjustable.

PLC Control: Mitusbishi of Japan.
Electricity: 380V/50Hz/3pH
Dimmension of Machine Line: 1900mmx1100mmx1500mm
Weight of whole line: 2.2Tons.

Levelling Unit for the metal Sheet Embossing Machine Line.
5 rollers coated with rubber for stratening coils after embossed.
Dia of roller: 70mm.
Material of Roller: 45#steel coated with hard chrom.
Motor Power: 2.2 KW.

Recoiler with Coils Car for the metal Sheet Embossing Machine Line.
Max Weight: 5 Tons
Material Width: 1000mm Max.
Material I. D: 508_610mm.
Material O. D: 1200mm.
Thickness of steel coils or aluminum sheets before embossing: 0.4mm.
Rotation Power: 5.5 KW
Tension Power: 2.2 KW
Speed: 8_15m/m.
Speed Control: Frequency Converter.
