Model:Y81-2000
Send Inquiry
Main Technical Specifications
1 | Main cylinder | Type | YG320/200-1620 | Quantity | 1 SET | ||
Nominal force | 2000KN | Stroke | 1620mm | ||||
2 | Side Cylinder | Type | YG200/120-1200 | Quantity | 2SET | ||
Nominal Force | 800KN×2 | Stroke | 1200mm | ||||
3 | Cover Cylinder | Type | YG180/120-1235 | Quantity | 1SET | ||
Nominal Force | 640KN | Stroke | 1235mm | ||||
4 | Gate cylinder | Type | YG160/105-440 | Quantity | 1SET | ||
Nominal Force | 500KN | Stroke | 440mm | ||||
5 | Hydraulic System Pressure | 25MPa | |||||
6 | Pressure Box Size (mm) | 1600×1200×800 | |||||
7 | Cycle Length | App.14 See | |||||
8 | Bale Size(mm) | 400×400 | |||||
9 | Motor | Type | Y200L2-6 | Nominal Power | 15KW | ||
Nominal Speed | 970rpm | Quantity | 2SET | ||||
10 | Hydraulic PumpContact Infomation
