Model:hscb
Send Inquiry
Model | HSZ-CB1T | HSZ-CB1.5T | HSZ-CB2T | HSZ-CB3T | HSZ-CB5T | ||
Capacity (T ) | 1 | 1.5 | 2 | 3 | 5 | ||
Lifting Height (M) | 2.5 | 2.5 | 2.5 | 3 | 3 | ||
Load chain | No.of fails | 1 | 1 | 1 | 1 | 1 | |
Demension | 6*18 | 7.1*21 | 8*24 | 10*30 | 9*27 | ||
Force of full load | 250 | 265 | 335 | 372 | 360 | ||
N.W/G.W(KG ) | 14.5/15 | 16.5/17 | 19.5/20.1 | 32/34 | 41.1/43.6 | ||
Demension (mm) | A | 149 | 176 | 176 | 231 | 249 | |
B | 153 | 173 | 173 | 185 | 185 | ||
C | 29 | 35 | 35 | 39 | 49 | ||
D | 41 | 51 | 51 | 49 | 67 | ||
Hmin | 352 | 385 | 385 | 445 | 615 | ||
Additional weight per 1M lift | 0.8 | 1.1 | 1.4 | 2.2 | 3.8 | ||
Price FOBTianjin | US$34.5 | US$42.6 | US$47.8 | US$62.7 | US$90.7
| ||
