Stainless steel sieving mesh is made of stainless steel wire.It is widely used in screening and seperation in mine, coal, grain, medicine, ceranic, glass, food, scientific research and other fields.
Materials: AISI 201, 202, 302, 304, 304L, 3016, 410, 430 stainless steel wire.
Weave: plain weave, dutch plain weave, twill weave, dutch twill weave.
Features:
* High filtering capability at high pressure.
* Excellent anti-corrosion.
* Low pressure loss.
* Constant mesh opening.
* Good dimensional stability.
* High open surface area.
Applications: to sieve and filter in the acid and alkali environment. Stainless steel sieving mesh is used as sieve mesh in petroleum industry, as filter-mesh in chemical industry, as screening and seperation in mine, also used in galvanized industry.
Specifications:
Mesh/Inch | Wire Diameter(mm) | Aperture(mm) | Width(m) |
20*20 | 0.5 | 0.77 | 1.5--4 |
40*40 | 0.27 | 0.365 | 1.5--4 |
60*60 | 0.21 | 0.213 | 1.5--4 |
70*70 | 0.18 | 0.183 | 1.5--4 |
80*80 | 0.15 | 0.167 | 1.5--4 |
90*90 | 0.14 | 0.142 | 1.5--4 |
100*100 | 0.13 | 0.124 | 1.5--2 |
120*120 | 0.08 | 0.131 | 1.5--2 |
140*140 | 0.07 | 0.111 | 1.5--2 |
150*150 | 0.063 | 0.106 | 1.5--2 |
160*160 | 0.063 | 0.015 | 1.2--1.6 |
200*200 | 0.056 | 0.071 | 1.2--1.6 |
250*250 | 0.04 | 0.061 | 1.2--1.6 |
300*300 | 0.035 | 0.054 | 1.2--1.6 |
325*325 | 0.035 | 0.051 | 1.2--1.6 |
350*350 | 0.035 | 0.042 | 1--1.2 |
400*400 | 0.03 | 0.0385 | 1--1.2 |
