Max Torque: 80KN.m

Max.drilling dia. 1000mm

Max.drilling depth:28m(4section)/22m(3section)

Engine Type:  Cummins

Working Speed:8-30rpm

Max Cylinder Thurst: 90KN

Max Hoist Capacity: 120KN

Main Winch Pull Force 80KN

Main Winch Speed: 80m/min

Auxiliary Winch Pull Force: 35KN

Auxiliary Winch Speed: 40m/min

Max Cylinder yrip: 2000mm

Mast Side Raking:±3°

Mast Raking Forward: 4°

Max Operation Pressure : 34.3Mpa

Max Pilot Pressure: 3.9Mpa

Max Moving Speed: 2.8km/h

Max Tractive Force: 98KN

Operating Height:12580mm

Operating Width: 2600mm

Trabsport Height: 3250mm

Transport Width: 2600mm

Transport Length:9150mm

Total Weight: 22t
