Model:dpair
electroscope，rheoscope，Gold leaf electroscope，high-voltage electroscope
Product introduction: by testing through the electroscope on stray capacitance, the current inspection equipment, line is charged device.
1. Inspection the high voltage ac lines and equipment have power frequency voltage.
2. Sound and light alarm, dual display, ensure the safety to work
3. Easy to carry, high sensitivity, and not by the strong electric field interference, have the whole circuit self-checking function, long standby time, etc.
Specification | ||||||||
Model | GSSB—0.4KV | GSSB—6KV | GSSB—10KV | GSSB—35KV | GSSB—110KV | GSSB—220KV | GSSB—330KV | GSSB—500KV |
Nominal voltage | 0.4KV | 6KV | 10KV | 35KV | 110KV | 220KV | 330KV | 500KV |
Starting voltage(KV) | 0.06≤Ut≤0.16 | 0.9≤Ut≤2.4 | 1.5≤Ut≤4 | 5.25≤Ut≤14 | 16.5≤Ut≤44 | 33≤Ut≤88 | 49.5≤Ut≤132 | 75≤Ut≤200 |
Shrinkage state length
| 200mm | 350mm | 480mm | 590mm | 740mm | 900mm | 1000mm | 1100mm |
Stretch state length
| 930mm | 930mm | 1490mm | 2000mm | 2740mm | 4000mm | 4520mm | 5300mm |
Handgrip length
| 100mm | 200mm | 200mm | 300mm | 400mm | 500mm | 600mm | 700mm |
Work environment | Environmental temperature -25---55℃，Relative humidity 20-96% | |||||||
In the guarantee product quality and under the premise of safety,the electroscope's length can be customized according to user requirements | ||||||||
