Pneumatic operated tilting column
Technological Features:
1. Full automatic pneumatic tilting column with pneumatic lock
2.24” large turntable and powerful motor, suitable for low profile tire

Technical specification of PL-1221 Car Tire Changer

Motor power 0.75kw/0.55kw/1.1kw
Power supply 220V/400V/110V
Max. wheel diameter 41"(1040MM)
Max. wheel width 14" (355MM)
Outside clamping 10"-21"
Inside clamping 12"-24"
Air supply 8 bar
Bead breaker force 2500kg
Noise level <75dB
Weight 240/217kg
Package size 960x760x1030mm
