Water Pump
2016-11-02 20:09  Views:184
Price:Negotiable
Model:JLM
Send Inquiry

Detailed introduction to Water Pump:

Product Description

Flow:0-15 lph

Pressure: 0-10Bar

Power:28W, 220V/110V, 50/60Hz,

Drive System: single and two phase motor

Protection Degree: IP55

Flow Control: Manual operation



Work Condition

Envitonment temperature: -30°C --- 60°C



Package

Material: Paper carton

Measurement: 31 x 28 x 18cm

Gross Weight: 4 kgs



Material

Pump head: PVC, PVDF           Diaphragm: PTFE           Valve: PVC, PVDF

Valve ball: Ceramic                  Valve seat: Viton           Tubing: PE



Accessories Bag-----for free





Technical Parameter

Model

Flow (lph)

Pressure (Bar)

Frequency ((min-1)

Caliber (mm)

Power (W)

JLM0110

1

10

0-90

6

28

JLM0408

3.8

7.6

0-150

6

JLM0505

5

5

0-180

6

JLM0804

7.6

3.4

0-180

6

JLM1002

10

2

0-180

6

JLM1202

12

1.5

0-180

6

JLM1501

15

1

0-180

6

















Features

  • Manual control the stroke frequency from 0-100%,LED display the normal frequency(at running or stop).
  • Glandless and leakage free diaphragm pumps.
  • Low power consumption.
  • Drive by electromagnetism,simple design,the speed of stroke is adjustable.
  • Easy to install, the pump is together with foot valve, injection valve and tubes for import and export.
  • Suit for low pressure water treatment industries.

    •

    Purpose

    Widely used in petroleum, chemical industry, metallurgy, mining, shipbuilding,light industry, agriculture, national defense department, daily chemicals, food industry, constructions industry, and etc.
