ITEM

UNIT

DATA

WORKING

PERFORMANCE

SPECIFICATIONS

MAX.RATED LIFTING CAPACITY

MAX.LIFTNG MOMENT WITH MIN.BOOM LENGTH

MAX.LIFTNG MOMENT WITH MIN.BOOM LENGTH

BOOM MAX.LIFTING HEIGHT

JIB MAX.LIFTING HEIGHT

Kg

KN.m

KN.m

M

m

8000

280

138

18.1

23.9

WORKING

SPEED

SINGLE LINE MAX.SPEED

LIFTING BOOM EXTENDING TIME

LIFTING BOOM ELEVATING TIME

SLEWING SPEED

m/min

s

s

r/min

105

35

25

0-3

TRAVELLING

SPECIFICATIONS

MAX.TRAVELLING SPEED

MAX.GRADEABILITY

MIN.TURNING RADIUS

MIN.CLEARANCE

APPROACHANGLE

ANGLE LF DEPARTRURE

Km/h

%

m

mm

.

.

74

24

8.2

265

30

11

DIMENSION

SPECIFICATIONS

OVERALL DIMENSIONS(L×M×H)

OUTRIGGER LonGITUDINAL SPAN

OUTRIGGERTRANSVERSAL SPAN

BOOM LENGTH

BOOM ANGLE

JIB LENGTH

m

m

m

M

.

m

8.3×2.48×3.22

3.9

4.2

7-17.4

-2~78

6

CHASSIS

TYPE

ENGINE  MODEL

MAX.POWER OF ENGINE

MAX.TORQUE OF ENGINE

KW/RPM

N.m/rpm

CA5115JQZ

CA4DF3-14E3

108/2500

490/1400

MASS

SPECIFICATIONS

SELF-WEIGHT IN TRAVELLING CONDITION

FRONT AXLE LOAD

REAR  AXLE LOAD

Kg

Kg

Kg

10895

3205

7690
