Detailed introduction to small truck cranes:
Lifting performance
| QLY5Z Lifting performance | |||
| Model | QLY5Z | ||
| Chassis | Chassis for the cable car | ||
| Lifting load | 5 | ||
| Lifting height ( M ) | 18-20 | ||
| Swing radius | 360° | ||
| Outrigger span | 3.73m * 3.85m | ||
| Fully-extending | Min working radius(75°) | 4.7m | |
| Max working radius(45°) | 13.4m | ||
| Dead weight in working | 6.17 tons | ||
| Dimensions | 8.2 (L) × 2.0 (W) × 2.7 (H) | ||
| Engine model | CF -28M | ||
| Power type | Diesel | ||
| Displacement/Power(ml/KW) | 1593 | 20.23 | |
| Emission standard | GB18322_2002 | ||
| Quantity of types | 6 | ||
| Types | 7.00-16 | ||
| Tread ( Front/Back ) mm | 1490 | 1490 | |
| Wheel base ( mm) | 3200 | ||
| Axles | 2 | ||
| Cab ( person ) | 2 | ||
