Detailed introduction to 24M37M39M42M45M48M52Mconcrete boom pump:
| name | unit | parameters | |||||
| HDT5280THB -37/4 | HDT5350THB -42/4 | HDT5380THB -45/5 | HDT5400TH B-48/5 | ||||
| Main technical parameters in working condition | Transport capacity in theory | M3/h | 125 | 125 | 125 | 125 | |
| Pumping capacity index | MPa.*M3/h | 586 | 586 | 586 | 586 | ||
| Max.concrete pressure | Mpa | 8.5 | 8.5 | 8.5 | 8.5 | ||
| Bucket volume | L | 620 | 620 | 620 | 620 | ||
| Bucket top surface height from the aggregate place | mm | 1370 | 1400 | 1400 | 1400 | ||
| Distribution valve form | S pipe valve | S pipe valve | S pipe valve | S pipe valve | |||
| Max. aggregate carrying radius | m | 32.6 | 38 | 40.7 | 43.7 | ||
| Max. aggregate carrying height | m | 36.6 | 41.8 | 44.7 | 47.7 | ||
| Max. aggregate carrying depth | m | 25 | 28 | 31.3 | 34.3 | ||
| Open height of aggregate carrying pipe | mm | 8450 | 10000 | 8495 | 9065 | ||
| Distance between front landing legs | mm | 6200 | 8500 | 9550 | 9780 | ||
| Distance between rear landing legs | mm | 6600 | 8500 | 9550 | 9860 | ||
| Distance between front and rear landing legs | mm | 7100 | 8490 | 9190 | 9470 | ||
| Delivery pipe's diameter | mm | 125 | 125 | 125 | 125 | ||
