Model:LTD6.3
Send Inquiry
Detailed introduction to hoist of LTD6.3:
| Model | LTD6.3 | LTD8.0 |
| Rated hoisting load | 6.3KN | 8.0KN |
| Lifting speed | 9.3m/min | 8.3m/min |
| Motor Power | 1.5KW | 1.8KW |
| Diameter of available steel wire rope | Φ8.3mm | 8.6mm |
| Self weight | 51KG | 53KG |
The suspended access equipment is provided two LTD6.3 hoists with power of 1.5kw (ZLP630 type) or LTD8.0 hoists with power of 1.8kw (ZLP800 type), which are installed in the erection frames of hoists at both ends of the suspension platform. The hoist is the power facility to drive the suspension platform to move up and down.
