Model:UTM-20T
UTM-20T Tensile Strength Testing Machine/tensile testing machine price
1. Main technical parameters
No. | Model | UTM-20T |
a | Capacity | 20KN |
b | Grade / Class | Class 0.5 (Class 1) |
c | Loading measuring range | 0.4% ~ 100% F.S (1% ~ 100% F.S) |
d | Loading accuracy | ±0.5% (±1%) |
e | Loading force resolution | 1/±200,000 F.S (same resolution in full range) |
f | Deformation min. reading value | 0.01mm |
g | Displacement speed control range | 0.2 ~ 500 mm/min |
h | Effective test span | 400mm |
i | Effective tensile test space | 800mm |
j | Effective compression test space | 700mm |
k | Loading method | Electric |
l | Control method | Micro-computer controller automatically control |
m | Working voltage | 220V±10%, 50Hz (good earth-connection) |
n | Motor power | 400W |
o | Dimensions (mm) | 740×450×1600 |
p | Weight | 400kg |
2. Functions and characteristic
a. This series testing machine adopt oil pressure sensor to measure force, electronic extensometer to test tensile deformation and computer to process the operational data.
b. Real time high speed sampling is adopted and at the same time, force-deformation, force-time, deformation-time test curves are recorded.
c. The test measurement range realizes automatic impact-free switch-over, the results are processed and the data are stored automatically, the data and the curves are dynamically displayed.
d. When the testing is over, the elastic modulus, yield strength and non-proportional extension stress, etc. are automatically calculated.
e. On the basis of automatic analysis, the results can also be amended manually to improve the analysis accuracy.
3. Purpose and characteristic
a. It can be used for the stretching, compressing, bending and shearing tests for metal and non-metal materials.
b. It is widely used in the industries and sectors, such as machinery, metallurgy, scientific research units, colleges and universities as well as quality control centers and commodity inspection, etc.
c. Therefore, the testing machine is an ideal selection for the sectors, such as manufacture, quality control, scientific research and education, etc.
