Model:JP60-PB
Send Inquiry
Detailed Product Description
mortar plaster machine
1.ISO9001:2000;export 6years
2.mix&spray mortar, fireproof
3.capacity:7-40L/min,pressure:25bar
JP60-PB mortar plaster machine
Integrating functions of mixing, storing pressurized conveyance and spray coating of different kinds of mortar, fireproofing material, fine polymer & foam concrete ,it's provided with a engine drive system and a hydraulic transmission control system to freely adjust the quantity of conveyance and plaster ,and also is available for driving traction.
Technical parameters
| Model | JP60-PB |
| Plastering motor power | 4.0 Kw |
| Mixer motor power | 1.1KW |
| Mixing drum volume | 120L |
| Air compressor motor power | 2.2kw |
| Air compressor output capacity | 25bar |
| Plastering output capacity | 40L/min |
| Theoretical delivery distance | 0-80m |
| Net Weight | 350kg |
| Dimension | 2290x680x1220 (with mortar mixer) |
