XCMG ZL50G wheel loader( export standard, and with C6121( CAT 3306 engine)

 Fully hydraulic powered steering with flow-amplified system. Pilot operated control for loader hydraulic system, power shift transmission makes convenient and flexible operating.
       XCMG new Z-bar linkage, high breakout force, shorter hydraulic cycle time, automatic leveling on any position, and greater productivity.
       Special quadrate type transmission shaft of construction machinery. Power transmission is more reliability.
       EG-TM combination is supported on three points by dual directions, vibration-isolators. Reducing resonance and fatigue failure of structure.
       Optimized structure of diesel engine air intake system reduces dust into air filter. Prolonging the durability of engine, convenience the service of air filter element.
       Optimized cooling system, drops overall heat balance temperature
       Integral openable hood, made by compound material, reduces noise and vibration, makes convenient and flexible operation and service.
Equipped with SHANGHAI STYRE,CAT or CUMMINS diesel engine, electric starting, electric stopping, having excellent performance and reliability.
1. ZL50G wheel loader features fully hydraulic poered steering with flow-amplified system, Pilot operated control for loader hydraulic system, power shift and electric shift optional transmission makes convenient and flexible operating.
2. XCMG wheel loader new Z-bar linkage, high breakout force,short hydraulic cycle time,automatic leveling on any position,and higher prductivity.
3. Special quadrat type transmission shaft of construction machinery. Power transmission is more reliable for heavy equipment.
4. Integral new luxury cab, excellent visibility, safty and reliability for wheel loader.
5. EG-TM combination is supported on three points by dual directions, vibration-isolators. Reducing resonance and fatigue failure of structure.
6. Optimized structure of diesel engine air intake system reduces dust into air filter, Prolonging the durability of the engine and conveniencing the service of air filter element. Optimized cooling system drops overall heat balance temperature.
7. Integral openable hood made of compound material reduces noise and vibration,and makes operation and service more convenient and flexible.
8. ZL50G wheel loader Equipped with SHANGHAI,STYRE,or CUMMINS diesel engine, which is of electric starting,electric  stopping and excellent performance and reliability. It approves to be one of the best wheel loader in China.


Specification XCMG ZL50G Wheel Loader

Size:                                               L*W*H 8110*3000*3460mm
Rated load                                                5t
Operating weight                                    18t
Max.tractive force                                  145KN
Static side rolling-off load
Min.ground clearance
Steering angle                                    35
Min.turning radius                               6400MM
Speed
1st(F)                                                   0-11.5km/h
2nd(F)                                                   0-37km/h
Reverse
1st,2nd                                               0-16.5km/h
F3/ R3
F4/ R4
Hoisting height
Tractive height
Engine
Engine model                           WD 615.67G3-31A(6CT8.3-C)
Rated power/speed                     162kw/2200r/min
Cylinder/bore/stroke
Standard Bucket capacity                    3m3
Optional Bucket capacity
Max.brake-out force                      170KN
Raising capacity
Total cycling time                               <11s
Dumping reach                                  3090mm
Dumping distance                       1130mm
Tools for optins
Tires                                                     23.5-25
Layer number
Engine options Cummins engine,Shangchai C612109L(import oil pump) or Shangchai C612150L ( CAT 3306 engine)

We also sell XCMG ZL30G, ZL50G wheel loader ( new and used one both)
