Introduction of alluminum corrugation machine

The long span aluminum corrugated roof sheets Making Machine is a metal roll former manufacturing long-span prepainted color alluminium roof cladding panel with good quality. It consists of decoiler, sheet guiding equipment, roll forming section, cutter, supporter, hydraulic system, control system. The colour roof and wall panels which made by this metal corrugation machine have neat external appearance, even ripples, high utilization and strong strength.

Main Technical Parameters

1.Material Spec: Q235 or 34 KSI ; Thickness : 0.4 mm to 0.7 mm
2.Hydraulic decoiler Max. Capacity: 5000kgs
3.Controlling system: PLC
4.Main machine power: 4kw Hydraulic station power: 2.2kw
6.Working speed: 15-20m/min
7.Type of cutting: roll-formed and length-set cutting
