Model:MD
Send Inquiry
Brife introduction:
Which CD1/MD1 model electric hoist has compact structur , light weight,small size,conveient operation, etc. It can be installed in the overhead alone , also can duplicateto complete installation manual monorail, in electric or doubl beam, Bracket. Longmen etc. Use cranes in the fineindustry,electric hoist model CD1 when the lifting speedcannot meet the requirements shall be chosen, MD1 model of double playsrise speed electric hoist.
Technical Date:
| Model | KCD-05T-KCD-16T | |||||||||
| Weight (t) | 0.5 | 1 | ||||||||
| Lifting height (m) | 6 | 9 | 12 | 6 | 9 | 12 | 18 | 24 | 30 | |
| Lifting speed normal speed (slow speed)(m/pm) | 8 (0.8) | |||||||||
| Running speed (m/pm) | 20 (30) | |||||||||
| Wire rope | Diameter of the rope (mm) | 4.8 | 7.4 | |||||||
| Diameter of the line (mm) | 0.22 | 0.34 | ||||||||
| Structural style | D-6 x37+1 | |||||||||
| I-beam track modle (GB706-65) | 16~28B | |||||||||
| The minimum radius of O ring track (m) | 1.5 | 1.5 | 3 | 4 | ||||||
| LiftingElectricmotor | Model | ZDI21~4 (ZDSI0.2/0.8) | ZDI22~4 (ZDSI0.2/1.5) | |||||||
| Capacity (k/w) | 0.8 (0.2/0.8) | 1.5 (0.2/1.5) | ||||||||
| Rotating speed (r/m) | 1380 | |||||||||
| Phase | 3 | |||||||||
| Voltage (V) | 380 | |||||||||
| Current (A) | 2.4 (0.72/2.4) | 4.3 (0.72/4.3) | ||||||||
| Frequency (c/s) | 50 | |||||||||
| Running electricmotor | Model | ZDYI11~4 | ||||||||
| Capacity (k/w) | 0.2 | |||||||||
| Rotating speed (r/s) | 1380 | |||||||||
| Phase | 3 | |||||||||
| Voltage (V) | 380 | |||||||||
| Current (A) | 0.72 | 1.25 | ||||||||
| Frequency(c/s) | 50 | |||||||||
| Connection times (t/ph) | 120 | |||||||||
| Working rate (JC%) | 25% | |||||||||
