Skype:uautotestProduct information More service in a compact format: EPS 200 with automatic test sequenceFor economic and all-round testsThe automatic test sequence of the new EPS 200 by Bosch only needs a minimum amount of time to determine if the component being tested is fit for further use. The EPS 200 allows quantity measurement with test specifications, the measurement of pre-injection, idle, reverse and full-load quantities for CRI and CRIN. Warranty evaluations during nozzle testing can be produced with combined air tightness tests, power seat tightness tests and measurement of the nozzle opening pressure.

Compact workshop tester for every workshop



Excellent economy with automatic test sequences



Easy use by touch screen



Integrated database for filing test specifications and customer data



Delivery-quantity-based injector tests



With integrated suction and purging program/device for common-rail injectors

•

EPS 200
Technical data

Degree of protection

IP 34



Width

560 mm



Height

580 mm



Depth

780 mm



Weight

112,0 kg

EPS 200
Standard AccessoryEPS 200 (400V)For checking nozzle-and-holder assembly (Bosch and external brands), unit injectors and solenoid valve CRI (Bosch applications)SKU 0 683 803 200EPS 200 (200 V)For checking nozzle-and-holder assembly (Bosch and external brands), unit injectors and solenoid valve CRI (Bosch applications)SKU 0 683 803 201EPS 200 A (400 V)As EPS 200 inlc. CRI Delphi/Denso, CRIN-BoschSKU 0 683 803 202EPS 200 A (200 V)As EPS 200 incl. CRI Delphi/Denso, CRIN-BoschSKU 0 683 803 203Scope of delivery

Basic device EPS 200 ( 1 687 020 414/415)



Injection chamber ( 1 682 312 042)



Connecting Adapter M12 and M14



Hose lines



Adapter lines



Mains cable (1 684 461 106)



Power unit (1 687 022 890)



CD/DVD drive 371 (1 687 022 932)



Oil catcher pan (1 685 411 077)

Special accessories

CRI Delphi/Denso, CRIN Bosch (1 687 001 872)



UI adapter set for comm. vehicles (1 687 010 147)



UI adapter set for pass. cars (1 687 001 857)



UI adapter Nissan (1 681 335 111)



Nozzle-and-holder assembly connector (1 683 391 193); Note: Radial use



Nozzle-and-holder assembly connector (1 683 391 194); Note: for testing UI nozzles



Nozzle-and-holder assembly reducing adapter (1 680 362 047); Note: M 16 x 1.5 (comm.vehs.)



Nozzle-and-holder assembly reducing adapter (1 680 362 000); Note: M 18 x 1.5 (comm.vehs.)



Nozzle-and-holder assembly reducing adapter (1 680 362 001); Note: M 22 x 1.5 (comm.vehs.)



Nozzle-and-holder assembly reducing adapter (1 680 362 044); Note: M 24 x 1.5 (comm.vehs.)



Nozzle-and-holder assembly reducing adapter (1 680 362 002); Note: M 26 x 1.5 (comm. vehs.)



Nozzle-and-holder assembly reducing adapter (1 680 362 045); Note: M 27 x 1.5 (comm. vehs.)



Printer PDR 371 (1 687 001 850)

SKU 0 683 803 20x
