Model:-
YUTONG 6600 series trash compacting machine,garbage compactor, Landfill Compactor6620/6623/6626/6628 trash compactor,Landfill CompactorThe garbage compactor is a vital device for the landfill site, being capable of leveling, crushing and compacting garbage. Members of this garbage compactor family are self-propelled articulated four-wheel machines,, with high gradeability... Standard configuration1. Mechanical front/rear four-wheel drive, four-wheel brake.2. SHANGHAI DIESEL ENGINE Caterpillar C6121 water-cooled supercharged engine;3. The separated type hydraulic torque converter and power gearshit transmission case is adopted;4. The compacting wheel is fitted with the specially-arranged wearable tooth;the mud scrapping tooth and cutting tooth are fitted in front and at the rear of each compacting wheel;5. The America No-Spin automatic interlock differential is fitted inside the driving axle;6. The imported centralized lubrication system;7. Drug sprinkling system as the standard configuration;8. The driver cab is fitted with 7-inch LCD flat board reversing monitor; two rain-proof cameras at high and low positions; SIEMENS VDO sound system ;negative ion generator; heating and cooling air conditioner; fan; fire extinguisher;9. The upturned drive cab is adopted for the convenience of maintenance;10. ROPS structure is equipped;
Main technical parameters | ||||||
| Item | Unit | 6620 | 6623 | 6626 | 6628 | |
| Engine | C6121ZG51 | C6121ZG60 | ||||
| Rated power | KW | 155 | 187 | |||
| Working weight | KG | 20000 | 20000 | 20000 | 28000 | |
| Rolling width | mm | 3330 | 3800 | |||
| Height of bulldozer shovel | mm | 1930 | ||||
| Width of bulldozer shovel | mm | 3400 | 3860 | |||
| Lifting height of bulldozer shovel | mm | 1200 | ||||
| Soil-cutting depth of bulldozer shovel | mm | 200 | ||||
| Max.gradeablity | % | 100 | ||||
| Ground clearance | Mm | 460 | ||||
| Max.driving speed | Km/h | 9.5 | ||||
| Overall dimension(L*W*H) | mm | 7785*3400*3770 | 7785*3860*3770 | |||
