imported CUMMINS B3.9-C engine, in accord with Tier 2 emission, energy saving and environmental protection, maintenance convenient, adopt radial seal air cleaner and air pre-cleaner, effectively extend the engine' s service lifetime, and equipped with standard fuel filling pump and pressure transmitter, effectively improve the fuel economical efficiency.

imported hydraulic components, with stable and reliable quality, high working efficiency and big digging force, equipped with standard pressure transmitter.
Equipped with new-generation electronic control system: Big color LCD, can real time monitor the operating state of the machine, having the self-diagnosis and record functions, electronic control throttle, many kinds of operating modes to be selected.

Engine: Cummins B3.9-C ( Tier 2)
Rated Power ( Kw/ Rpm) : 86/ 2200
Displacement ( L) : 3.9
Traveling Speed ( H/ L Km/ H) : 3.59/ 5.57
Swing Speed ( R/ Min) : 12.6
Bucket Capacity ( M3) : 0.55
Operating Weight ( Kg) : 12800
Ground Pressure ( Kpa) : 39
Fuel Tank ( L) : 238
Hydraulic Oil Tank/ System Capacity ( L) : 120/ 208

Max digging height ( mm) : 8495
Max digging depth ( mm) : 5537
Max dumping height ( mm) : 6065
Max digging distance ( mm) : 8297
