Detailed production description

Rebar tying machine, a hand-held power tool, can tie the crossed rebars speedily and automatically. Powered by the rechargeable battery it can be used alternatively and continuously. It is widely usded in the construction field, which can highly improve the working efficiency.



Package:BMC plastice box+Carton

Contents(1set)

1pc Rebar tying machine

2pcs Batteries

1pc charger

4pce of spool wire(L100M/SPOOL)

1pc of inner hexagon spanner

1pc of sharp nose pliers

Two kinds battery

9.6V NI-Cad 2500mAh

9.6V Ni-MH 2800mAh

Max Tying Diameter:21mm

Length of Wire for Tying: 380mm/2 turns/510mm/3 turns

Charge time:1 hour

Turns per Tie: 2 turns/3turns

Ties per Coil: Approx. 260ties(2turns)

Charger:110-240V 50/60HZ

Max:Tying knots

1000knots(Ni-cad battery)

1200knots(Ni-MH battery)

Tying time:0.8 second/knot

Dimension of the products:398mmx150mmx410mm

Packing box size:408x162x418MM

Gw of mahince:2.1kg

Gw of one set:7.5kg

Certificate:CE and Rohs
