Model Number:QTZ63B

Rated Lifting Moment:63T.M

Rated Loading Capacity:1T

Max.Lifting Capacity:6 T

Freestanding Height:41 M

Attaching Height:161 M

Span:56 M

Mast Section Size:1.835 M*1.835 M*2.5 M

Wall-attached frame(SET):6

Main Material:135*135*10 Angle Steel Welding

Hoisting Speed(a=2):80/40/10 M/MIN

Min.Stable Falling Speed:5 M/Min

Slewing Speed:0-0.62 R/Min

Jacking-up Speed:0.6R/Min

Radius-changing Speed:40/20 M/Min

Total Motor Power:55.2Kw

Power Supply:380V/50Hz

Independent Weight:36.8T

Counterweight:14.85 T

base Form: Built-in Type (Outrigger Stationary)
