Model:QTY12-15
QT12-15 paving brick making machine
1.Paticular storage and segregation material systerm insure the feeding accuracy and avoiding the effect of exterior material. So the products have high desity.
2.Adopting synchronization vibration insures the products making average. the frequency can change according to different technics .low frequency in feeding material, high frequency vibration makes the different material to have a optimal vibration way.
3.the computer is of fault diagnosis system. Warning signal is propitous to eliminate the fault. Combine with long-distance controlling system, it can achieve scrutiny,controlling, diagnosis
QT12-15 main production specification & theoretical productivity
itme | specification size(mm) | qty /mold | cycle molding | per hour |
hollow brick | 390*190*190 | 12pcs | 20~25s | 1728~2160pcs |
porous block | 240*115*90 | 30pcs | 15~20s | 2400~7200pcs |
standard brick | 240*115*53 | 62pcs | 15~17s | 12700~14400pcs |
QT12-15 Main technical parameter
1 overall dimension:9350*2520*2950mm
2 rated pressure:21Mpa
3 mian vibration form: platform virbraiton
4 vibration frequency:2800~4500(r/min)
5 palllet size:1300*900mm
6 molding cycle:15-25s
7 overall power:44kw
