Price:Negotiable
Model:JOY-1212
Send Inquiry
Parameters
| Model | 1212 | 1218 | 1224 |
| X Y working area | 1200*1200mm | 1200*1800mm | 1200*2400mm |
| Z working area | >100mm | >100mm | >100mm |
| Table size | 1500*1500mm | 1500*2100mm | 1500*2700mm |
| Max travel speed | 5.5m-8m/min |
| Max engraving speed | 2m-4m/min |
| Resolution | 0.005mm |
| Reposition accuracy | 0.05mm |
| Max feeding height | 100mm |
| Command | G code*.u00*.mmg*.plt |
| Software | windows98/2000/xp |
| Power(not include the spindle) | 300W |
| Power | AC220V-380V/50Hz |
| Main axle rotating rate | 1.5KW-2.2KW |
| Main axle rotating speed | 0-24000rpm/min |
| Work Mode | stepper |
| |
Detailed Product Des
cription:1. To be filled out with Germanic double-nut ball screw automatic arc gap2 .Linear guide and surface contact, orbit has high precision. Lifespan is 2200 times than the ordinary orbit.3. Co
ntinue engraving after point breaks and blades breaks .Hold more than 9 points, engrave at discretion.4. Good compatibility, Compatible software CAD/CAM, such as Type3, Artcarm, Proe, CorelDraw, Wentai, etc. It can manufacture fancy Emboss, Shadow engraving and 3D arts.5. Large power frequency water cooling spindle, it can cut 20-30mm Perspex at a time. It is used for advertising, mould, gift, architecture, furniture mould and so on.
