The lifting capacity of the main hook: 500T

The lifting capacity of auxiliary hook: 100T

Span: 13m to 31m

Lifting height: 20m/22m

Working class: A5

The speed of the main hook: 2m/min

The speed of the auxiliary hook: 4.7m/min

Trolley travelling speed: 26m/min

Crane travelling speed: 38m/min

The max wheel load: 741kn to 928kn according to difference of the span

Total power of the motor: 699kn to 735kn according to the difference of the span

Recommended steel track: QU120

Power: 3 Phase 80V 50Hz

Structure: Bridge, running gear of the crane, trolley, electrical device, etc.

The operation control is all done in the cabin.

It has three ways to enter the cabin: From the side, from the end and from the top.

The buffer of the crane can raise about 250mm.



OEM orders are welcome.

Your requirements about the products will be highly appreciated.
