Model:QT4-35
Manual QT4-35 Brick making machine,concrete brick making machine.
Feature:
1. Use four channel steel stander to make the machine frame more stable.
2. Have super-vibration motor,adopt upper mould and bottom mould vibrating together to produce high density and quality brick.
3. Can use various kinds of materials,reduce the cost.
4. Have ISO9001 certificate.
5. Environment friendly,
Technical parameter
Model | Manual QT4-35 |
Qty per mould | 390x190x190mm 4pcs 390x240x190mm 3pcs |
Molding cycle | 45s |
Productivity | 2200pcs-2700pcs |
Vibration frequency | 2800r/min |
Exciting Power | 32KN |
Power | 9.7KW |
Dimension | 2050x1660x1900mm |
Pallet size | 850x450mm |
Weight | 1300KG |
Raw material | Crushed stone,sand,cement,dust and coal fly ash,cinder,slag,gangue,gravel,perlite and other industrial wastes. |
