Wheel Loader FDM720
Standard Description
WeiChai Engine R4110 65KW (RICARDO), Hydraulic Torque Converter with Single-Turbo and Countershaft Gear Box, Two Rockers, 2.0 Tons of Load, 1.2 m3 Bucket, Longer Arm (Dump Height: 2.65m), 16/70-20 Tire, Full Hydraulics Steering System, 4WD, 4 Wheel Disc Brakes, Paint and finished in A Grade.

Standard equipment
Weichai Engine R4110G1 65KW/2400rpm
Single-turbo hydraulic torque converter and countershaft gear box
Feicheng drive axle
Two-way valve, boom and bucket
Jack(lifting cylinder) and dump cylinder
Standard boom
Adjustable seat
Caliper disc brake
Accumulator 2 * 12V
Alternator 28V 750W
Motor 24V 4.2KW

Optional Equipment (with different payment)
Engine YTO LR4108G84A 65KW/2400rpm
ROPS(roller protective structure)
Loose material bucket, rock bucket, quenched integral cutting edge bucket
Side dump device, clamping (pipe or grass) device, high dump device
Cool air, warm air, air-condition (cool & hot).

Specification
Engine: WeiChai Engine R4110
Rated power: 65kw/2400rpm
Overall dimensions
Overall length: 5950mm
Overall width: 1950mm
Overall height: 2800mm
Dump height: 2650mm
Dump reach: 890mm
Tread width: 1900mm
Tires type: 16/70-20
Performance parameters of entire machine
Operating weight: 6200kg
Bucket capacity: 1.2m3
Rated loading capacity: 2000kg
Digging Depth(bucket lean forwards 10 degree)  269mm
Turning radius: 5250mm
Gear box  FUDA
Number of shifts (forward/reverse):  2/2
Fuel tank capacity  100L
Hydraulic fuel tank capacity: 100L
Lifting time: 5.5s
Total cycling time  10s
Travel speed
Forward gear I  9 km/h  Reverse gear I  9 km/h
Forward gear II  22km/h  Reverse gear II  22 km/h

Advantage
*The design for automatic dust removal of engine exhaust is good for maintenance;
*Single-turbo hydraulic torque converter together with countershaft gear box, this simple makeup enables convenient repair and high work efficiency;
*4-wheel caliper disc braking system ensures safer and reliable operation;
*Steering system adopting constant current exposed circuit steering system makes steering performance at different speed and linear travel stable;
*Higher dump height and bigger dump reach can satisfy more work requirement;
*Z-form connecting rod has strong breakout force and high raising ability, and enables high operating efficiency;
*Support of two rocker-arms enables stable performance;
*A broad view and a comfortable seat enable easy and flexible operation;
*Knock-down cab enables a wide work range;
*Rational matching parts, superior machine performance and extraordinary operating efficiency;
*Various optional equipments and buckets can satisfy different needs of customers.
