Model

FD100




Rated load


10000kg




Load center


600mm




Lift height


3000mm




Length (without fork)


3990mm




Width


2130mm




Height


2600mm




Fork size


1220*175*80mm




Min. turning radius


4000mm




Max. travel speed


26km/h




Service weight


12500kg




Engine


Yuchai 6108 92kw power diesel engine


Optional: ISUZU 6BG1 diesel engine, full free 2-Stage mast with 2000~4000mm lift height, full free 3-Stage mast with 3700~6000 lift height, solid tire, cabin and all kinds of attachments, such as sideshifters, fork positioners, paper clamps, push/pulls, carton clamps, rotators, bale clamp, pulp bale clamp, foam rubber clamp, tobacco carton clamp, drum clamp, fork clamp, block clamp etc.
