Model:QT03-20A
Send Inquiry
| QT03-20A(cost-effective,semi-automatic) | Overall Dimension | Exciting Power | Main vibration | Vibration frequency(r/min) | Pallet Size (MM) | Molding Cycle | Overall power |
| 5500*1120*2600mm | 52KN | Platform vibration | 4500-5100 | 680*540 | 15-30(s) | 17kw | |
| Productivity | Size(mm) | Quantity/ Pallet(pcs) | Molding Cycle (s) | Output (pcs/10h) | |||
| Standard | 240*115*53 | 20 | 15 | 48000 | |||
| Hexagon revetment brick | 200*400*80 | 1 | 30 | 1800 | |||
| Lawn brick | 400*200*80 | 3 | 28 | 4320 | |||
| Color-face brick | 200*100*60 | 12 | 16 | 17280 | |||
| Lock linkage blocks | 225*112.5*70 | 10 | 18 | 14400 | |||
| Porous | 240*115*90 | 10 | 21 | 12000 |
