CD Wire rope electric hoist
1. Capacity 0.25-50tons Lifting height 6-100m Duty class-M3
2. It can mounted on single beam overhead cranes.
3. It is essential in raising working efficiency and improving working conditions.
4. Gantry Cranes, Jib Type CD,Eletric hoist as only one normal Speed which can satisfy normal application.
5. It is widely used in factories, mines, haybours, wirehouses, cargo storage area and shops.
Technical parameters:
| Model | CD1 0.25T | CD1 0.5T | CD1 1T | CD1 2T | CD1 3T | CD1 5T | CD1 10T | CD1 16T | CD1 20T |
| Capacity T | 0.25 | 0.5 | 1 | 2 | 3 | 5 | 10 | 16 | 20 |
| Standard lifting height m | 3-9 | 6-12 | 6-30 | 6-30 | 6-30 | 6-30 | 9-30 | 9-18 | 9-18 |
| Lifting Speed m/min | 8 | 8 | 8 | 8 | 8 | 8 | 7 | 3.5 | 3.5 |
| Running Speed m/min | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Wire rope type | 6X9 | D-6X37+1 | D-6X37+1 | D-6X37+1 | D-6X37+1 | D-6X37+1 | D-6X37+1 | 6X37+1 | 6X37+1 |
| I-beam track type | 16-22b | 16-28b | 16-28b | 20a-32c | 20a-32c | 25a-63c | 25a-63c | 45a-63c | 50a-63c |
| Loop track minium radius m | 0.8 | 1.5 | 1.5-4 | 2-4 | 2-4 | 2.5-5 | 2.5-9 | 3-4.6 | 3-4.6 |
| Power supply | 220V-440V,3phase,50/60HZ | ||||||||
| Working Duty | Mid M3 | Mid M3 | Mid M3 | Mid M3 | Mid M3 | Mid M3 | Mid M3 | Mid M2 | Mid M2 |
