Single drum vibratory rollers 22ton to 10tons
2016-11-02 23:24 Views:203
Price:Negotiable
Model:LT220B LT218B
Send Inquiry
LT220B LT218B LT216B LT214 LT212 LT210 eavy duty vibratory rollers effect powerful centrifuga force and great static linear load, They are suitable for non-cohesive materials, such as sandy soil,gravel,crushed stones, rock fillings and slightly cohesive soils, designed for large foundation constructions such as high-class highways, mines, dams, airports, harbors, railways and industrial areas etc.
Main Features
Mechanical travel drive, double amplitude, hydraulic vibration and steering with optimal function/price ratio and reliable performance.
Reliable D6114 or YC6108 diesel engine for convenient operation and maintenance.
Two sets of brake devices, a hand brake and foot pedal brake, assure the machine's safety and dependability.
Spacious and comfortable cab mounted on top quality rubber damping elements.
World advanced technology is adopted for the hydraulic vibration technology, high in reliability, simple and convenient in maintenance, and low in cost.
Equipped with padfoot or removal padfoot as option. |
| Main Technical Parameters | | | | LT210 | LT212 | LT214 | LT216B | LT218B | LT220B | | Operating mass | Kg | 10000 | 12000 | 14000 | 16000 | 18000 | 20000 | | Static linear load | N/cm | 230 | 276 | 342 | 378 | 415 | 450 | | Vibration amplitude | Hz | 30 | 30 | 30 | 30 | 30 | 30 | | Vibration fraquency | mm | 0.9 | 1.8 | 1.8/0.9 | 2.0/1.0 | 1.0 | 2.0 | | Centrifugal force | kN | 240/130 | 270/140 | 200/150 | 320/180 | 340/200 | 360/220 | | Travel speed | Hz | | | | | | | | 1st gear | | 1.8 | 1.8 | 2.0 | 2.0 | 2.0 | 2.0 | | 2nd gear | | 3.7 | 3.7 | 4.0 | 4.0 | 4.0 | 4.0 | | 3rd gear | | 9.7 | 9.7 | 10.5 | 10.5 | 10.5 | 10.5 | | Grade ability | % | 35 | 35 | 35 | 35 | 35 | 35 | | Turning angle | | 35 | 35 | 35 | 35 | 35 | 35 | | Ground clearance | mm | 360 | 360 | 432 | 432 | 432 | 432 | | Bectrical voltage | v | 24 | 24 | 24 | 24 | 24 | 24 | | Turning radius | mm | 6500 | 7000 | 7000 | 7500 | 7500 | 7500 | | Vertical oascill ation | | 8 | 8 | 8 | 8 | 8 | 8 | | Type size | | 17.5-25 | 17.5-25 | 23.1-26 | 23.1-26 | 23.1-26 | 23.1-26 | | Overall length | mm | 5640 | 5640 | 5820 | 5820 | 5820 | 5820 | | Overall width | mm | 2258 | 2258 | 2278 | 2278 | 2280 | 2280 | | Overall hieght | mm | 2970 | 2970 | 3000 | 3000 | 3000 | 3000 | | Vibration round width | mm | 2100 | 2100 | 2100 | 2100 | 2100 | 2100 | | Drum diameter | mm | 1400 | 1400 | 1600 | 1600 | 1600 | 1600 | | Drum rim thickness | mm | 24 | 24 | 24 | 32 | 40 | 46 | | Wheelbase | mm | 3080 | 3080 | 3160 | 3160 | 3160 | 3160 | | Diesel model | | YC6108G | YC6108G | YC6108G | YC6108ZG | D6114ZG6B | D6114ZG6B | | Diesel power | kW | 85 | 85 | 85 | 105 | 132 | 132 | | Diesel speed | r/min | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | | Fuel tank capacity | L | 180 | 180 | 180 | 180 | 180 | 180 | | Hydraulic tank capacity | L | 150 | 150 | 150 | 150 | 150 | 150 |
|
