Model:QLS50
Forward Plate Compactor QLS50
Features
1.Foldable handle for easy transportation and stock
2. Open plate provides self-cleaning.
3. Built-in wheel for easy transportation.
4. Heavy-duty shock mounting reduces vibration to the upper engine & handle.
5.Sealed belt cover prevents sand and soil in.
6. Round edge protects the exciter housing and even objects around working site.
7. Lifting hook as standard part
8.Throttle control is available as optional
Technical Specification:
Model: | QLS50 |
Engine: | Air-cooled, 4-cycle, single cylinder |
Engine Type: | Chinese Petrol Engine |
Power kw (hp): | 1.8 (2.5) |
Operation Mass kg (Ibs): | 54(119) |
Frequency (vpm) | 5900 |
Centrifugal Force (kn): | 8.2 |
Compaction depth (cm/in): | 20(8) |
Travel Speed cm/s ( in/s): | 37 (15) |
Efficiency m2/hr (ft2/hr): | 350(3733) |
Plate size cm (in): | 43x31(17x12) |
Dimension cm (in): | 90x31x88(35x12x34) |
Optional
(Rubber mat)(Wheel)
