Model:HHYG Series
Send Inquiry
Certificat :CE
Hydraulic cylinder
Light weight and easy to carry.
Baked enamel finish for increased corrosion resistance
All the raw material specially heat-treated and proccessed by imported CNC lathes.
imported high quality seals to provide better protection to the cylinder, making the cylinder not easy to wear out.
1. Rated output from 10 metric tons to 600 metric tons
2. Stroke from 50mm to 300mm
3. Oil storage volume from 72CC to 25659CC
4. Closed height from 97mm to 650mm
Welcome to contact us for more information of the products
| Model | Tonnage | Stroke | Oil capacity | Matching pump | Closed height | Weight |
| (T) | (mm) | (cc) | (mm) | (kg) | ||
| HHYG-1050 | 10 | 50 | 72 | HHB-700C | 97 | 2.5 |
| HHYG-10100 | 10 | 100 | 145 | HHB-700C | 147 | 4.5 |
| HHYG-10150 | 10 | 150 | 217 | HHB-700C | 226 | 7 |
| HHYG-2050 | 20 | 50 | 141 | HHB-700C | 105 | 5 |
| HHYG-20100 | 20 | 100 | 282 | HHB-700 | 165 | 7.5 |
| HHYG-20150 | 20 | 150 | 423 | HHB-700 | 230 | 11 |
| HHYG-3050 | 30 | 50 | 210 | HHB-700C | 108 | 5.5 |
| HHYG-30100 | 30 | 100 | 418 | HHB-700 | 167 | 9 |
| HHYG-30150 | 30 | 150 | 627 | HHB-700A | 233 | 15 |
| HHYG-5050 | 50 | 50 | 318 | HHB-700 | 113 | 9 |
| HHYG-50100 | 50 | 100 | 635 | HHB-700A | 173 | 13 |
| HHYG-50150 | 50 | 150 | 953 | HHB-700A | 243 | 18 |
| HHYG-10050 | 100 | 50 | 623 | HHB-700 | 136 | 19 |
| HHYG-100100 | 100 | 100 | 1246 | HHB-700A | 232 | 34 |
| HHYG-100150 | 100 | 150 | 1869 | HHB-700A | 282 | 40.5 |
| HHYG-20050 | 200 | 50 | 1280 | HHB-700A | 182 | 55 |
| HHYG-200100 | 200 | 100 | 2543 | HHB-630A | 232 | 73 |
| HHYG-200150 | 200 | 150 | 3810 | HHB-630A | 282 | 82 |
| HHYG-25050 | 250 | 50 | 1820 | - | 234 | 88 |
| HHYG-250150 | 250 | 150 | 5480 | - | 334 | 135 |
| HHYG-250300 | 250 | 300 | 10970 | - | 440 | 206 |
| HHYG-30050 | 300 | 50 | 2281 | - | 290 | 152 |
| HHYG-300150 | 300 | 150 | 6843 | - | 390 | 200 |
| HHYG-300300 | 300 | 300 | 13685 | - | 540 | 271 |
| HHYG-40050 | 400 | 50 | 2800 | - | 360 | 223 |
| HHYG-400150 | 400 | 150 | 8399 | - | 460 | 283 |
| HHYG-400300 | 400 | 300 | 16797 | - | 610 | 374 |
| HHYG-50050 | 500 | 50 | 3653 | - | 385 | 320 |
| HHYG-500150 | 500 | 150 | 10959 | - | 485 | 399 |
| HHYG-500300 | 500 | 300 | 21918 | - | 635 | 518 |
| HHYG-60050 | 600 | 50 | 4276 | - | 400 | 384 |
| HHYG-600150 | 600 | 150 | 12829 | - | 500 | 475 |
| HHYG-600300 | 600 | 300 | 25659 | - | 650 | 611 |
