Model:Auto machine
Delivery date:Since payment date 30 Days delivery
| Model Number: YQT5-15 | ||
| Type: Paving Block Making Machine | Processing: Brick Production Line | Brick Raw Material: Concrete |
| Method: Hydraulic Pressure | Automatic: Yes | Capacity: 5 pcs/mold |
| Power: 35kw | Logo: OEM | Color: Blue & White |
| Hydraulic Valves: Yuken | PLC System: Mitsubishi | Block Forming Method: Table Vibration + Press |
| Mould: 100,000 times without cracks | Product: brick making machine |
Packaging & Delivery
| Packaging Detail: | 1.Seaworthy packing Standard 2.PE film for Host machines 3.Wooden boxes for all accessories |
| Delivery Detail: | 30days after 30% deposit or L/C /confirm/iation |
Automatic brick making machine:
1.Hydraulic: YUKEN
2. PLC: Mitsubishi
3.Certificate: CE SGS
4.Guarantee: One year
Automatic block making machine
QT6-15, QT8-15, QT12-15 block making machine uses imported PLC control system, HMI automatic failure diagnosis. The vibration system uses electro-hydraulic proportional valve control to achieve a low feeding and high vibration molding frequency. The feeding system installed with multi-row stirring fork, can quickly and evenly discharges the material into the mold box; through the replacement of molds, it can produce a variety of blocks, standard brick, and multi-hole brick. It is ideal equipment for the production of new type materials for wall.
Features and advantages
1. It has simple overall structure and with special welding technique. Four-oriented pillars not only ensure a stable and precise molding, but also adapt to the replacement of various molds, serving several purposes;
2. The whole process uses PLC intelligent control system, with features of easy operation and high degree of automation;
3. Adoption of hydraulic drive technology, high-frequency vibration compression molding, to achieve high-density, high strength molding effect;
4. Uses unique compulsory shaft-rotating feeding device, which is with new structure, attractive appearance, uniform feeding, high efficiency;
5. Special wear-resistant mold extends the service life and effectively reduces the cost.
Specifications
| Model | QT6-15 | QT8-15 | QT12-15 |
| Vibration frequency(times/min) | 2700-3800 | 3800-5100 | 3800-5100 |
| Forming cycle(second) | 15 | 15 | 15 |
| Power(KW) | 26 | 36.5 | 38 |
| Weight(T) | 10.8 | 12.5 | 14.8 |
| Pallet size(mm) | 900x600x35 | 980x820x40 | 1300x850x40 |
| Dimensions(mm) | 3200x1900x2600 | 6930x2030x2750 | 6930x2650x2850 |
| Hollow brick | 6pcs(390x190x190) | 8pcs(390x190x190) | 12pcs(390x190x190) |
| Multi-hole brick | 15pcs(240x115x90) | 21pcs(240x115x90) | 30pcs(240x115x90) |
| Holland brick | 18pcs(200x100x60) | 24pcs(200x100x60) | 36pcs(200x100x60) |
| Standard brick | 30pcs(240x115x53) | 42pcs(240x115x53) | 60pcs(240x115x53) |
