Model:AAC plant
Certificate of AAC(autoclaved aerated concrete) line: ISO/CE/CIECC
Style: automatic.
Method: Hydraulic pressure.
Capacity:30000-300000m3/annual.
The porous rate:70-80%.
Density: 400-700kg/m3(concrete usually:1600-2400 kg/m3)
Block size: length 600mm,
width 100/125/150/200/250/300mm,
height 150/200/250/300mm.
Equipments : raw materials storage, grinding machine, mixing machine,molding maching, curing, roll-over hanger ,cutting machine, autoclave, crane, transporting system etc.
The advantages of the AAC brick making line:
1.labour-saving:The AAC production line of our factory has material supplying system,material scale machine,block transporting system,hydraulic reversal system,pallet reuse system pcking system and so on.Thus this production line is highly-automatic and intelligentialized which can greatly save you labour cost.
2. qualified bricks: Hydraulic and variable frequency block blank hanger assures the blanks stay completely still during the transporting and cutting process.This can greatly improve the rate of finished products.
The advantages of the bricks made by AAC Line:
1.light weight; 2.heat and sound insulation; 3.anti-shock; 4.good plasticity; 5.less labour and less intensity;6:high profit.
AAC brick raw material: Fly ash or sand, cement, quicklime, gypsum, aluminum powder.
Power:250~1250KvA.
fly ash style aerated block raw material proportion table
name | unit | Cement lime fly ash |
flash | % | 65-70 |
cement | % | 6-15 |
lime | % | 18-25 |
gypsum | % | 3-5 |
Aluminum powder paste(600kg/m3) | 1/10000 | 8 |
Water & material rate |
| 0.60-0.65 |
Casting system | OC | 36-40 |
Aluminum mixing time | S | 30-40 |
Sand style aerated block raw material proportion table
Name | Unit | Cement Lime Sand |
Sand | % | 55-65 |
Cement | % | 10-20 |
Lime | % | 20-30 |
Gypsum | % | 2-3 |
Aluminum powder paste(600kg/m3) | 1/10000 | 8 |
Water & material rate |
| 0.65-0.75 |
Casting system | OC | 35-38 |
Aluminum mixing time | S | 30-40 |
The details for the advantages of the AAC bricks:
Aerated concrete density is usually 600-800kg/m3(according to the market in production), same as 1/3 of clay brick and 1/5 of common concrete, so use the light brick can reduce the weight of the building, and also reduce the beam of roof and pillar press, also you can see, it can save the material cost
It has many porous, the delivery hearting coefficient is 0.9-0.22W/MK, so it is the best construction materials in the world now.
We are the top leader in China in manufacturing the autoclaved aerated concrete line(aac), we have exported our lines to many countries -------Vietnam, India, Russia, Thailand, Ukraine, Middle East and so on.
We can offer our customers designing, production, installation, commissioning, training and good after-sales service.So wish we can cooperate as business partners as well as friends.
