CG942H standard wheel loader has the following features:
1. This front end loader is powered by Xichai CA6113ZG engine and CG transmission for strong power output.
2. Wet axle
3. Its dual pump flow hydraulic system is of good power efficiency and low power consumption.
4. Pilot control and A/C
5. It adopts an imported fully hydraulic braking system.
6. Load sensing hydraulic steering system
7. CG942H standard wheel loader has a strong breakout force and long dump reach.

Parameters

Operating weight 12800kg
Rated load 4000 kg
Bucket capacity 2.3 m?
Maximum pulling force 136kN
Digging force 136kN
Working cycle time 12s
Max. Dumping height 3094 mm
Max. Dumping reach 1328 mm
Wheelbase 2915 mm
Wheel track 2020 mm
Min. Turning radius 5760 mm
Max gradeability 30?
Max. Speed 35km/h
Length 7694 mm
Width 2540 mm
Height 3340 mm
Engine Xichai CA6113ZG
Rated power of engine 128 Kw
