Specified in SC/SCD series construction elevator, the details of our product:

Operating by gear and rack, we not only absorb more advanced technique from local or foreign special company, but also rennovate by practice, which let our machine more beautiful appearance, more stable function, more reasonable operation process. We offer the model of treble drive, inner put type and outer put type. And this product has no counter weight, dismantling easily and working safely.

Main parameter:

1.Load capacity:2000kg/1500kg/1000kg per cage

2.Independence height:15m

3.Lifting speed:33m/min

4.Max lifting height:150m

5.Person capacity:24 per cage

6.Cage dimensions:3*1.3*2.4m

7.Section dimensions:65.*65.*1508mm

8.Safety breaker type:SAJ3.0*1.2/SAJ4.0*1.2

9.Motor power:11*3/11*2kw
