Block Forming Machine QT8-15
2016-11-03 00:33  Views:82
Price:Negotiable
Model:QT8-15
Send Inquiry

QT8-15 Type Block Forming Machine Multi Functionality

QT8-15 Type Block Forming Machine has multi use,strong adoption,the many kinds of products with different form and size can be made when change the different molds ,such as tiles along the road, river brick, slope protection brick, square brick, driveway brick, sidewalks brick, road brick,planting grass brick,slope block.


The concrete block products has good compressive strength ,accurate dimension, small discreteness, each block can guarantee the strength. Fully meet the quality "of concrete hollow block", "GB8239-1997" National Standard.

QT8-15 Type Block Forming Machine adopts innovative hydraulic vibration technology, forced feeding device, solution vibration, , advanced units combine vibration of the work table and mold , noise in line with the requirements of environmental protection, large output, multi-function, can meet the needs of different materials, particularly suitable for composite material production process ,which is a latest type to eliminatethe traditional models.

QT8-15 Type Block Forming Machine Technical Parameter
ItemTechnical Specification
frame dimensions(mm)2700x2150x2600mm
Pallet size(mm)950 x 850 x 20mm
Vibration frequency(r/min)2800-4700r/min
Host Power(kw)35.3kw
Net weight(kg)8500kg
Cycle time(s)15-25s
The way of Vibrationtable mould resoance

PictureDescriptionSpecificationPieces/blockOutput
 Porous brick240x115x90mm213900 pieces/h
 Standard brick240x115x53mm427980 pieces/h
 Block390x190x190mm81360 pieces/h
 Ground brick225x112.5x60mm213780 pieces/h
