DM-CNC06 CNC  Foam Cutting Machine

The machine is our newest development of the CNC contour cutting machine, adopts PC computer + multi-axis motion control card system,and using the 3mm width serrated circular cutter two or three dimensional polyurethane foam or similar materials, Cutting precise, operate easily, so the product widely used for varies field, such as heat preservation materials, furniture, mattress, packing, Air conditioning and ventilation pipes ,other industrial usage.

Technical Specification:

1.Maximum cutting size:W2000*L2500*H1200MM      Cutting precision:±1.00MM

2.Processing Speed: 0-10 m / min  adjustable timely

3.Cutting method: circular blade cutting

4.blade t speed: stepless 0-1200 m / min adjustable

5.Blade  speed: stepless 0-1200 m / min adjustable

6.Software: YCUT special foam cutting system

7. the motor control system using stepper servo system

8.  control systen: PC computer + multi-axis motion control card
9. blade specifications: L11900 * W3 * 0.6MM circular blade

10.Total power: 8KW
11.External dimensions:  L5000 * W4000 *H3000MM
