sell Composite dry type Wall bushings
2016-11-03 01:31 Views:57
Price:Negotiable
Model:FCWB-35/630
Send Inquiry
| Product Name: | Composite dry type Wall bushings 10kV-630A |
| Composite dry wall bushings are new style wall bushing. Applying new type insulating materials for inner insulation and high temperature sulfurated silicone rubber for outer insulation, they perform excellent anti-pollution capacity and explosion proof. They are consistent with current developing trend of requiring no oil and miniaturization by electricity sector. They are new generation HV products meeting the requirement of urban & rural power network improvement. | | No . | Type | Total
Length
(mm) | main part
Length
(mm) | Main body
Length
of outdoor
(mm) | Max.
Diameter
of shed
(mm) | Min nominal
creepage
distance of
outdoor end(mm) | Bending
failing
load(kN) | Power frequency withstand voltage | Full wave lightning
impulse withstand
voltage (peak
value)(kV) | Rated
voltage of
bushing (kV) | Wet
(kV) | Breakdown
(kV) | Visible
halation(kV) | | 1 | FCWB-10/600 | 540 | 460 | 250 | 110 | 380 | 7.5 | 30 | 75 | / | 75 | 10 | | 2 | FCWB-35/600 | 980 | 870 | 435 | 178 | 1030 | 7.5 | 80 | 176 | 185 | 185 | 35 |
|
|
