Model:yt24
Send Inquiry
1. YT24 Pneumatic Rock Drill , Air leg Rock Drill , YT24 rock drill is suitable for drill level or gradient holes in medium hard or hard rock. YT24 Rock Drill is a high efficiency air leg rock drill machine, It is widely used for blasting holes and other drilling projects in a quarries, railway construction, water conservancy construction and defense project facility. It can be matched with the FT140BD short air-leg or FT140B long air-leg to use in the basis of the width of rock. Also it can be fixed on drilling-vehicle or drilling-shelf. 2. Parameters
| Item Name | YT24 | ||
| Weight | 24kg | ||
| Overall dimensions | 678mm | ||
| Stoke | 70mm | ||
| Cylinder Dia | 70 mm | ||
| Air pressure | 0.4-0.63mpa | ||
| Water pressure | 0.2-03mpa | ||
| Impact frequency | >31Hz | ||
| Air consumption | 66.7L/S | ||
| Drilling speed | 250mm | ||
| Max drilling depth | >6m | ||
| Air pipe inside dia. | 19mm | ||
| Water pipe inside dia. | 13mm | ||
| Drill bit size | 32-42mm | ||
| Drilll rod size | H22X108mm | ||
| FT140B air-leg | |||
| Length of air leg | 1,687mm | ||
| Drilling length | 1,250mm | ||
| Inner diameter of air cylinder | 60mm | ||
| weight | 15.6kg | ||
| FT140BD air-leg | |||
| Length of air leg | 1,400mm | ||
| Drilling length | 1,000mm | ||
Grouped control mechanism, quick to start up, with "air on ,water on, air off, water off" mechanism, convenient to handle and easy to maintain and repair.
Energy-saving and efficient, long service life of parts, parts highly interchangeable and reliable performance.
YT24 differs form similar products particularly in its high efficiency, strong flushing and powerful torque.
