Wedge wire slot tubes
Materials: 302, 304, 304L, 316, 316L stainless steel wire

The profile wire stainless steel pipe screen is created by wrapping a profile wire cylindrical around longitudinal placed support rods. All wires and rods are resistance welded at each point of contact.
V-Shaped Slots:
Openings shaped like a "v" that open toward the inside of the well tend to allow the particles that are just barely smaller than the width of the slot pass. In other shapes of openings, these particles would get caught in the screen and clog it.

Continuous Slots :
The special design gives continuous slot opening across the periphery and length of screen.

Better Sand Filtration :
Due to specialize manufacturing process, wide range of slot opening is available down to 0.15 mm to allow proper slot selection depending upon the size of sand in particular area.This gives better sand control and reduced pump maintenance and longer tube well life.

Characteristics: The welded stainless steel wire wrapped pipe screen is made up of rods and profile wire. The rod can be round wire,triangular wire or trapezoid wire. The profile wire is triangular wire (V-shaped wire). This type of pipe screen has a structure and high open area, as well as accurate slot dimension. At the same time, stainless steel pipe screen has heat-resisting, anti-corrosive, good machine capability, last long, safety and reliability and so on characteristics. It can be used in many kinds of medium filtering.

Min slot: 0.025mm
Filter: From outside to inside From inside to outside
Max length:6000mm
