samway slitter line cut to length line, for more interested , please visit our webpage.

Specicifications samway slitter lines
54" samway Turret Head Looping Slitter Line

Complete with 40,000# maximum weight coil entry
54" maximum width cuts through 1" minimum
Thickness 20 cuts of .015" through 5 cuts of .156"
Crop Shear, Looping Pit, and Tension Stand
40,000# maximum exit on 20"/24" ID
Connected to our new packaging system with automated conveyor and banding head

36" samway Slitter

36" maximum width cut through 3/4" min width cuts
Entering coils (pay off) 16"/24" ID
Exiting coils (recoiler)16"/20" ID<
8,500# max weight coil entry and exit<
Thicknesses: 20 cuts .019" through 4 cuts .081"

28" samway Slitter

28" Max width cut through 5/8" min. width cuts
Entering coils (pay off) 16"/24" ID
Exiting coils (recoiler) 20" ID
15,000# max weight coil entry and exit
Thicknesses : 12 cuts .029" through 4 cuts .187"

24" samway Slitter

24" max. width cut through 1/2" min. width cuts
Entering coils (pay off) 16"/24" ID
Exiting coils (recoiler) 16"/20" ID
10,000# max weight coil entry
5000# max weight coil exit
Thicknesses : 12 cuts .015" through 3 cuts .081"

samway Cut-To-Length Line

72" Absolute max. width
144" max. length - 48" min. length
.125" max gauge - .020" min gauge
Up to 50,000# min. yield
Up to 10,000# max. lifts
CR- HR - HRP&O - GALV
Crane capacity 40,000#

For thickness  more than 5 mm or production related questions please contact us for samway custmizing solutions.
