Model:GD-2600
Send Inquiry
GD Series Double-color Flexography Printing Machine
Application: Introduce sensitization resin as flexible printing plate, suitable for printing
such packing materials as polyethylene, polypropylene bag, cellophane and roll paper,
etc. It is a kind of ideal printing equipment for producing paper packing bag for food,
supermarket handbag, vest bag and clothes bag, etc.
| Model | YT2600 | YT2800 | YT21000 |
| Max.printing material width | 600mm | 800mm | 1000mm |
| Max.printing width | 560mm | 760mm | 960mm |
| Max.printing length | 191-914mm | 191-914mm | 191-914mm |
| Max.diameter of roller | 450mm | 450mm | 450mm |
| Printing speed | 5-50m/min | 5-50m/min | 5-50m/min |
| Plate thickness | 2.38mm | 2.38mm | 2.38mm |
| Total power | 8kw | 10kw | 12kw |
| Weight of machine | 1800kg | 2000kg | 2200kg |
| Machine dimension | 2300x1860X2145mm | 23002060x2145mm | 2300x2260X2145mm |
