Characteristic:

1. Worm wheel Reductor: Main machine overloading protect with lower noisy and stabile running.
2. Adjustable range of stroke: Can change the stroke dimension freely to suitable more kinds of product.
3. online mechanical detection and rejection device with 100% rejected rate
4. Double orientation shafts with spline shaft transmission adopted to ensure synchronization stabile.
5. Touch screen with PLC mould adopted, stabile operation and easy maintenance

Main function: Al/al mechanism forming, special automatic feeding, PTP alu foil plate sealing, perforation, embossing and blister cutting.
Suitable al/al blister packing for tables, capsules, irregular tablets and so on.
Main Technical Parameters:
Capacity 10-30 stroke/min
Rangel of stroke 40-120 mm
Packing material: Cold form alu: (0.09-0.15)*250mm
                                 PTP alu foil: (0.02-0.05)*250mm
Using requirement: Clean compressed air with 0.6-0.8MPa pressure.
Air consumption ≥ 0.3 m3/min
Power: 380V 50Hz 6.5KW
Water chiller for moulds: Tap water or recycle water with 60L/h consumption
Overall dimension(L*W*H): 3700*750*1700 mm
Net weight: 2000kg
