Packaging Machinery
vertical form-fill-seal machine with 10 heads combination weigher
2016-11-03 08:45  Views:260
Price:Negotiable
Model:GQK-398/520
Send Inquiry

It is suitable for the requirement of high precision measurement and fragile of loose materials packaging, such as: puffed food, potato chips, crispy rice, jelly, candy, nuts, peanuts, beans, apple flakes, dumplings, dumplings, medicinal materials, etc

1.    prin The machine complete the whole procedure of feeding ,measuring bagging ,date ting ,charging(exhausting),product out-putting automatically.

2.    High precision ,high efficiency without crash the materials.
technical parameters



Model

GQK-398

GQK-520

Film width

Max.420mm

Max.520mm

Film thickness

0.04-0.08mm

0.04-0.08mm

Bag making length

50-300mm

80-250mm

Bag making width

60-200mm

60-200mm

Filling range

Max.1500ml

Max.2000ml

Packing speed

15-90bag/min

10-70bag/min

Power specification

3.0Kw/220v.50/60Hz

3.0Kw/220v.50/60Hz

Outside dimension

1400*970*1700mm

1430*1200*1700mm

Gross weight

450kg

650kg
