BX-2600 Twin Type VFFS Machine - Sell

BX-2600 Twin Type VFFS Machine

2016-11-03 08:46 Views:134

Price:Negotiable
Model:BX-2600,BT-2500

The BT-2500 & BX-2600 V.F.F.S machine can run two bag simultaneously. They are designed to equip with the 14head multihead weigher & 16head multihead weigher.

Having two machines in one frame saves space & cost. only 11.2 sq.m. of floor space is needed for the high speed weighing and packing line, and value="5" unitname="m">5M for overall height equipped with 14head weigher.

Painted mild steel structure;product contact parts are stainless steel.	Fully stainless steel structure
Servomotor is loaded for single belt pulling film	Servomotor is loaded for double belt pulling film
Pneumetrically-operated, intermittent motion	Servo-drive for end seal jaws intermittent motion
Controlled by PLC (Mitsubishi) & interface	by Emerson PLC & Eview (Taiwan) interface
Up to 110bpm (double side);Max. 55 bpm per side	Up to 200bpm (double side) ;Max. 100 bpm per side
70value="200" unitname="mm">-200mm (W), 100value="280" unitname="mm">-280mm (L)	70value="240" unitname="mm">-240mm (W), 100value="300" unitname="mm">-300mm (L)
value=".36" unitname="m3">0.36m3/min, 0.6Mpa	value=".36" unitname="m3">0.36m3/min, 0.6Mpa
220V, 50HZ, 6KW	220V, 50HZ, 6KW
