Model:FA-210
Send Inquiry
It is suitable for catting various materials, double-sided plastic-sided.self-adhesive labels,foam,film,foil,and so on. Standard configurations:1 feeder,1 slicer,1 host,2 upper form boards for die-cutting,1 lower form board for die-cutting.
Optional accessories:1.lamination roller device;2.laminating protection film device added between mold base and babo wheel;3.receiver added on collecting stand;4.discharger added on collecting stand;5.roller to be wrapped with rubber;6.pressing wheel changed to rubber pressing ruller;7.add ejector pin for discharging;8.nipping wheel changed to nipping disk;9.multi-bar double-sided rubber laminated fixture;10.metal tooling;11.second-time magic eye tracking device.Parameters:
| Model | FA-210 |
| Maximum datum width(mm) | 215 |
| Die-cutting area(mm) | 200*190 |
| Die-cutting speed(times/h) | 1800-12000 |
| Machine power(kw) | 4 |
| Machine size(mm) | 1750*1050*1890 |
| Machine weight(kg) | 1400 |
